Mixed-signal ICs, designed to your specification.

You tell us what the chip has to do. We design the schematic and the layout, prove it in simulation, and hand you a verified GDS.

Our design tool with the window split in two: the schematic of a switching controller on the left and its full-chip layout on the right
Schematic and full-chip layout of the same design, side by side in one window — any area of the window can show any editor. Click to open it in the tool.
How it works
Your requirements→Schematic→Layout→Verified GDS

Every design is simulated across process, voltage and temperature, through start-up, load steps and every protection event, and checked by a second engineer before it leaves us.

What we design
Amplifiers and comparatorsOperational and transconductance amplifiers, sense amplifiers, comparators
References and biasBandgaps, current references, bias networks, trimming
Regulators and driversLinear regulators, switching controllers, gate drivers
Clocks and supervisionOscillators, timers, power-on reset, monitors and protection
Digital and mixed-signalControl logic and state machines, counters, serial interfaces, and the interfaces between logic and the circuit blocks of a mixed-signal chip
LayoutMatched and symmetric mixed-signal layout, guard rings, current-density aware routing
Our standard

Specified

We agree every target with you in numbers before the first transistor is drawn.

Proven

Corners, temperature, start-up and fault cases are simulated, with results you can read.

Reviewed

No result is approved by the engineer who produced it.

Our design tool

ADSP, our in-house design environment in development

Our own browser-based environment for mixed-signal design: schematic and symbol editor, simulation with pass and fail against the specification, waveform viewer and layout editor in one window. Nothing to install. The screens below are the tool itself, running the example you can open.

Schematic, simulation with live pass/fail against the specification, waveform analysis and full-chip layout live in one browser window. Open the worked example below and try it yourself: run its fourteen tests, plot the results and open the die layout.

Open the example in the tool   More about the tool

Selected work

Synchronous buck controller

Full-chip schematic, behavioural models of every block, layout and protection testing.

Low-dropout regulator

Low-quiescent-current regulator: schematic, block models and simulation across load and line.

Client names and part numbers are withheld.

Contact

Unlock and digitalize your design.

Tell us what your chip needs to do — send the function, the key specifications and your schedule. We reply with a scope and a plan.
